CHARGER SPECIFICATIONS
Input Voltage:
Low Cut-off : 180V AC
High Cut-off : 280 VA
Input Current:
2.5A ± 0.2A Less Power Consumption
Input frequency:
50 Hz ± 1% Less Power Consumption
Output Voltage:
54.6V ± 0.2V Lithium ion Battery
Output Current:
7A ± 0.2A Suitable for Lithium ion Batteries
Regulation:
± 2% Smart Battery Charging
Current and Watt Control
CV,CC and CW Constant Voltage, Constant Current and Constant Watts
Efficiency
More than 90% Low Power Consumption
Surface Charging
2A to 3A, After full charged, when BMS wake up, charging will start with 2 to 3A.
This helps equalize charging
Charging Cutoff
Usually charger is cutoff by BMS, when BMS cutoff not occurred then charger will automatic cutoff after 10 mins when output current reduces less than 1A.
Cooling
DC Fan, Inlet DC fan for fast cooling.
Weight
1.4 Kg (Approx)
Enclosure
Aluminum
Dimension
150L x 150W x 80H (mm) Compact Size
LED Indications
Battery full charged:-
Green LED will solid on.
Battery charging indication based on AH - Green, Yellow and Red LED Blinks:-
0 to 25% Red LED Blinks and after completion will glow solid
26% to 50% Yellow LED Blinks and after completion will glow solid.
51% to 75% Yellow LED Blinks and after completion will glow solid
76% to 100% Green LED Blinks and after completion will glow solid.
Fuse Blown RED LED:-
Fuse Blown Red LED will on
System on RED LED:-
When charger connect with AC System Red LED will on.
