AshvaVolt® 72volt 32Ah Lithium Ion Rechargeable Battery Pack With Premium Metal Box for EV, Solar Inverter, E-Bike, Toto Battery with BMS protection | 72v 32000mAh Lithium Ion Battery

Name: AshvaVolt® 72volt 32Ah Lithium Ion Rechargeable Battery Pack With Premium Metal Box for EV, Solar Inverter, E-Bike, Toto Battery with BMS protection | 72v 32000mAh Lithium Ion Battery
SKU: ASHV-72V32AH-NMC
Price: 30040 INR
Availability: InStock

SKU: ASHV-72V32AH-NMC

AshvaVolt Discount for New Customers

Hurry and get discounts on all Ashvavolt products up to 5%

Use code VOLT05

VOLT05

₹35,447

10 in stock

Compare

Add to wishlist

12 People watching this product now!

Xpressbees

Xpressbees courier will deliver to the specified address

3-5 Days

Free

Delhivery

Delhivery courier will deliver to the specified address

3-5 Days

Free

For fast delivery

Contact us via mail, WhatsApp, or call

1-2 Days

Chargeable

Charges may vary depending on the product and its weight

Free 7-Day returns

Payment Methods:

Description

Technical Specifications

Nominal Voltage – 72V
True Capacity – 32AH at 0.2C discharge
Series Parallel Configuration – 20S 13P
Watt hr – 2368WH
Weight – 14 KG Approx
Battery Dimensions (L*W*H) –35*25*20 in cm Approx
Customization of Dimensions is available
Full Charged Voltage – 84V
Discharge Cut-off Voltage – 59.5V
Standard Charging Current – 6A
Max Charging Current – 20A
Max Continuous Discharge Current – 40A
Peak Discharge Current – 60A (for few milli seconds)
Standard Charging Temperature – 0°C to 45°C
Discharge Temperature -20°C to 45°C
Storage Temperature – 20°C to 45°C
Life Cycles – 1200 Plus at 80% DOD (Life increases at low DOD)
Charging Mode – CC/CV
Over Charge Protection in BMS – 84V (4.2V per Cell)
Deep Discharge Protection in BMS – 57V (2.85V per Cell)
BMS Protections – Over Charging, Deep Discharging, Short Circuit Protection, Thermal Runaway Protection

Note: Charger is not included

72V

32Ah

AshvaVolt® Lithium-Ion Rechargeable Battery Pack For Electric Vehicle, Solar & Others EV 36Ah Battery for E Bike

Battery warranty –

2 year warranty is available with the battery against manufacturing defects.

SAFE OPERATION:

It is designed to the highest automotive standards.
A Class BMS ensures 24/7 battery performance and safety.
Protect against short circuit, cell over voltage, cell under
Voltage, charge over current and discharge under current.
BMS monitors all 16 cell series voltage for passive balancing

Its Higher in power, higher in Mileage than normal Lead acid Battery. Battery weight is also very light than lead acid battery. This battery is protected with over charge protection. Low discharge protection. This battery weight is very low than your normal lead acid battery. This Battery provides a lifespan of nearly 3 years where a normal lead acid battery sustain for only 1 year’s of life.

AshvaVolt 72V 32Ah portable battery pack is a compact, safe and economical Li-Ion battery pack. This standalone battery pack is designed for Electric Vehicle (Bike and Scooty) with high power NMC Li-Ion Cells.

No additional equipment is required for safe operation of battery pack.

In extreme operating conditions, BMS disconnect battery from the system. This ensure safe operation and protect the battery pack against short circuits, over-charge, over-discharge, over current and over temperature.

This Li-Ion battery pack is maintenance free, and has a longer run time with a shorter recovery time than equivalent lead acid battery packs. It weighs 70% less and takes 60% less space than equivalent lead acid battery packs, providing increased range product compatibility.

Use only lithium Ion charger for this battery. Do not use Lead acid Battery Charger.

SAFETY AND PRECAUTION

When charging the battery, use dedicated chargers and follow the specified conditions.
Do not connect battery directly to an electric outlet or high current application.
Do not heat or throw battery into a fire.
Do not use, leave battery close to fire or inside of a car where temperature may be above 60℃.
Also do not charge / discharge in such conditions.
Do not immerse, throw, and wet battery in water/ seawater.
Do not put batteries in your pockets or a bag together with metal objects such as necklaces,
Hairpins, coins, or screws. Do not store batteries with such objects.
Do not short circuit the (+) and (-) terminals with other metals.
Do not place battery in a device with the (+) and (-) in the wrong way around.
Do not pierce battery with a sharp object such as a needle.
Do not hit with a hammer, step on or throw or drop to cause strong shock.
Do not disassemble or modify the battery.
Do not use a battery with serious scar or deformation.
