Battery Specification
- Charging Voltage- 16.8V
- Charging Current- 2A
- Nominal Pack Voltage- 14.8V
- Capacity- 5200mAh
- Discharge Current- Tested for 1A, 2A, 3A
- BMS: Included
- Protection - Short circuit, Over-voltage and Under-voltage
- Configuration: 4S2P
- Cell Type: 18650
- Charging Method: DC Male Female connectors.
- Dimensions - 133* 36 * 40 mm Approx
- Dimensions Can be Customized
- Weight - 250 grams Approx
Protection (Included BMS)
- Short Circuit Protection
- Over voltage cut-off- 16.8
- Under voltage cut-off- 12.2V
Important: For some model of vacuum robots the connector type might be different, please check the connector type and polarity before buying. Contact customer care or whatsapp if you need a different type of connector or pin.
Applications:
- Small scale UPS Battery
- Battery for GPS Tracking - Vehicle Tracking - Asset Tracking
- WiFi Modem or Router Battery for backup
- PSP
- Industrial Machines
- Emergency Lights
- Robotics and RC cars
- Music Players and Audio Systems
This Li-ion Rechargeable Battery Pack has a nominal voltage of 12.6 volts and is a 3s battery pack. This battery pack contains three cells connected in series, giving it a capacity of 2600mAh. The battery pack has a built-in BMS that protects the battery from overcharging, over-discharging and short circuit.
Recommended Charger - Charging Time
- 14.8v 1.5A Lithium Battery Charger - 1Hr 45Min.
- 14.8v 2A Li-ion Battery Charger - 1Hr 10Min.
